Model H3.8—2000W

Generator body: mainly including generator, nose cone, and protection cover,Hummer generator, the most advanced in the world, wins 4 proprietary intellectual property rights. It is made of high-efficiency magnetic materials, special copper alloy, high-strength stainless steel and aeronautic aluminum alloys. It is extremely light and small but with high generating efficiency.

Nose cone:Made of reinforced aluminum alloy, it locates in front of blades to reduce the wind resistance. The generator is enclosed in the nose cone, which is favorable for heat dispersion.

Protection cover:Made of reinforced aluminum alloy, it locates between blades and nose cone to further reduce the wind resistance and protect the generator.

SKF Bearings:Two SKF bearings, famous in the world with good quality and a long history, make sure the system in reliable, safe and steady operation status.

Flange:Made of fine steel parts, it is used to fix the blades.

Blades:Made of glass reinforced plastic, they receive wind energy and convert it into mechanical energy. Every 3 blades compose one set and pass strict balance test before delivery, so please don’t disorderly use.

Yaw shaft:Made of fine steel parts, it is used to connect generator, blades, tail pole, tail wing with tower together.  With the slip ring, it can rotate at 360°.

Tail pole & Tail wing:Tail pole is light with high intensity and made of manganese steel.
Tail wing is made of stainless steel, inflexible, auto-deflection in high wind condition, reliable and sharp in speed limitation.
They are used in 2kw and below models.

Off grid inverter:Adopting SPWM technology, it will inverter with high converting efficiency, output stable frequency and stable voltage, filter out noise. It is used in the off grid system and power the electric loads.

Grid tied inverter:Adopting MPPT and IGBT technologies, It inverters with high power generating capacity and wide AC voltage range.  It connect with state grid and the energy storing device isn't needed.

Rectifier/ dumping controller:It rectifies AC current generated by wind generator into DC current and charge the battery bank.  It also controls the dumping load.

Dumping load:With metal dumping box, it quickly dissipates heat  by air convection. A fan isn't needed

   Specifications

Rated power (W)

2000

Maximum output power (W)

3200

Battery bank voltage (Vdc)

120

System output voltage (Vac)

110/220

Start-up wind speed (m/s)

3

Rated wind speed (m/s)

9

Working wind speed (m/s)

3-25

Survival wind speed (m/s)

50

Generator efficiency

>0.8

Wind energy utilizing ratio (Cp)

0.45

Generator type

Permanent Magnet Alternator

Generator weight (kg)

25

Blade material/quantity

GRP/3

Blade diameter (m)

Ф3.8

Speed regulation method

Yawing+Electromagnetism braking

Shutting down method

Manual+Automatic
